Dongying Lake Petroleum Technology
|
API F1000 triplex piston mud pump
| Price: | 150000.0 USD |
| Payment Terms: | T/T,L/C,WU |
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
F series mud pump is applicable to the requirement of high pressure in oil field and high displacement.
F series mud pump is applicable to the requirement of high pressure in oil field and high displacement.technological
of well drilling with its solid and compacts structure,small volume and outstanding operation performance.
F series pump is produced strictly according to API Spec 7K the Equipment Specification of well drillingand
repairing,and performed the EX-Word test under the specification thereof.This series pump is widely use in oil field
and other lines of industrial and mining enterprises,operation of drilling well and well repairing etc F-1600 mainly with
the adapted drilling machine 45-80.
Model | F-500 | F-800 | F-1000 | F-1300 | F-1600 |
Type | Triplex single acting | Triplex single acting | Triplex single acting | Triplex single acting | Triplex single acting |
Rated Power | 373kw | 596kw | 735kw | 969kw | 1193kw |
500HP | 800HP | 1000HP | 1300HP | 1600HP | |
Rated Speed | 165 SPM | 140 SPM | 140 SPM | 120 SPM | 120 SPM |
Stroke(mm/inch) | 190/7 1/2 | 254/10 | 254/10 | 305/12 | 305/12 |
Max.Liner Dia. | 170/6 3/4 | 170/6 3/4 | 170/6 3/4 | 180/7 | 180/7 |
Gear Type | Herringbone | Herringbone | Herringbone | Herringbone | Herringbone |
Valve Pot | API-5 | API-6 | API-6 | API-7 | API-7 |
Gear Ratio | 4.286:1 | 4.207:1 | 4.207:1 | 4.206:1 | 4.206:1 |
Suction Inlet | 203/8 | 305/12 | 305/12 | 305/12 | 305/12 |
Discharge Inlet | 4Flange | 5Flange | 5Flange | 5Flange | 5Flange |
5000 psi | 5000 psi | 5000 psi | 5000 psi | 5000 psi | |
Lubrication | Forced& | Forced& | Forced& | Forced& | Forced& |
Splash | Splash | Splash | Splash | Splash | |
Max. Pressure | 27.2Mpa | 34.5Mpa | 34.5Mpa | 34.5Mpa | 35Mpa |
3945 psi | 5000 psi | 5000 psi | 5000 psi | 5080 psi | |
Overall Size(in) | 144*106*86 | 163*89*70 | 163*89*70 | 174*121*78 | 181*129*106 |
Weight(kg) | 9770 | 18790 | 18790 | 24572 | 24791 |
